4x4 Omni Antenna for 5G E84977

The XPOL-1-5G is Poynting’s second-generation “V2” of this very popular Cross Polarised (XPOL), cellular band, 2x2 MIMO antenna. The addition of a 4X4 MIMO derivative is also available for user-specific needs. The antenna has been completely redesigned from the previous generation with an all-new enclosure and antenna design. The antenna now includes the newer 3400 - 3800 MHz bands as well as the in-demand lower 698 MHz band, which were not previously covered by our V1 and is suitable for 2G, 3G, 4G & 5G. This antenna performs exceptionally well in the following frequency bands: 698 – 960 MHz, 1700 –2700 MHz & 3400 – 3800 MHz, with a peak gain of 3dBi* across the frequency bands of operation. The radiation patterns of this antenna are omni-directional and exceptionally well controlled, further adding to the performance of the antenna. This makes the antenna perfect for most application areas, such as urban, rural, agricultural and commercial, to achieve the best possible coverage over a large area. The robust mechanical enclosure design makes the antenna weather, dust and vandal resistant and gives it an IP65 rating, suitable for harsh environments. The V2-21 XPOL is a 2X2 MIMO device, whereas the V2-41 XPOL is a 4X4 MIMO device. This refers to how many data streams each antenna can support simultaneously, which essentially boils down their maximum concurrent data bandwidth. 2X2 devices like the V2-21 contain two antennas, each supporting their own data streams. A 4x4 device like the V2-41 basically doubles this, with built-in antennas each supporting their own data stream for a total of 4 streams.
